The ICON Vehicle Dynamics 2023-2026 Ford F-250 and F-350 Super Duty 4.5" coil springs are designed for drivers demanding the ultimate in performance and ride quality, while allowing for increased wheel travel (when used with ICON shocks) and the fitment of larger tires. The ICON Ford Super Duty coil springs provide 4.5" of lift height and feature a dual rate design optimized for use with trucks equipped with gasoline engines. The dual rate design allows for a softer initial rate for superb on-road comfort and a firmer secondary rate that increases during compression for excellent bottoming resistance and off-road performance. Like all ICON coil springs, they feature a lifetime guarantee against sagging/breakage to produce confidence in knowing that you have the best suspension products available for the 2023-2026 Ford F-250/F-350 Super Duty.
Beyond the added ground clearance, the dual rate design of ICON springs provides a softer initial rate for superb on-road comfort and a firmer secondary rate that delivers excellent bottoming resistance and superior off-road performance.
APPLICATION NOTE #522: Brake line kit (Part # 61110) is recommended for end users who are looking for a braided stainless brake line upgrade
Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #521: Models equipped with Tremor package will have front lift height of 3.5" over stock
APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
Vehicle specific spring rates optimized for use with trucks equipped with gasoline engines
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5” Backspace / 6mm Offset
Dual-stage, semi-gloss powder coat offers excellent corrosion resistance
Dual rate coil springs improve on and off-road ride quality over stock
ICON 23-24 Ford F250/350 Front 4.5in. Gas Dual Rate Spring Kit
APPLICATION NOTE #156: Springs are rated for gasoline engines
23-26 FORD F-250/F-350 FRONT 4.5" GAS DUAL RATE SPRING KIT
100% bolt-on system makes for an easy install
Lifetime warranty against sagging/breakage
APPLICATION NOTE #1: Only fits 4WD models
Factory Wheels & Tires Fitment: Yes
4.5" lift height over stock
COIL SPRING KIT
Coil Spring Set
64013
